Details

Key Specifications

1. Capacity (20hr): 12V — 40AH
2. Design Life: 15 Years
3. Max. Discharge Current: 480A (for 5 seconds)
4. Max. Charge Current: 12A
5. Cycle Charge Voltage: 14.4 ~ 15.0V
6. Float Charge Voltage: 13.5 ~ 13.8V
7. Operating Temperature: -15°C ~ +50°C
8. Internal Resistance: 7.5mΩ
9. Weight: 14 kg
10. Dimensions: 199 × 166 × 171 mm
11. Terminal: F8 (M6 Bolt)
12. Warranty: 1 Year

Capacity Retention During Storage (20°C)

1. 1 Month: 92%
2. 3 Months: 90%
3. 6 Months: 80%

Features

1. Maintenance Free
2. Non-Spillable
3. UL94 V-0 flame retardant

For inquiries about compatibility or detailed specifications — contact our team
